The EGL IN Infusion Pump is an extremely accurate volumetric pump that is used for safe and precise medication administration in hospitals, ICUs, and emergency departments. It has advanced flow control, an easy-to-use interface, and a robust alarm system to provide patient safety. Compatible with the majority of standard IV sets, it has customizable infusion parameters, automatic reminders, and dual power support for continuous operation. Equipped with 3.5-inch TFT-LCD screen, A.B.S Anti-Bolus System, and secure memory feature, EGL IN Infusion Pump ensures effective, efficient, and smooth infusion therapy.
- Precise flow control with high accuracy to enable accurate administration of medication.
- Most standard IV sets are supported, with calibration customizable by user.
- 3.5-inch TFT-LCD monitor to monitor infusions in real time.
- Control and adjustments are easily handled through keypad operations.
- Deterrent system to prevent sudden bolus administration at high dose rates.
- Auto-stop of infusion during critical alarms.
- Dual power supply (AC/DC) with rechargeable internal battery.
- USB connectivity for firmware updates and calibration.
- Memory function stores infusion settings upon power-off.
| Volume Infused |
0.1~9999.9 ml, Step by 0.1 ml |
| Flow Rate |
0.1~1800 ml/h, Step by 0.1 ml/h |
| Accuracy |
±5% |
| Purge / Bolus Rate |
1~1800 ml/h adjustable, ±20% |
| KVO Rate |
Flow rate >10ml/h: KVO rate 3 ml/h
Flow rate ≥1ml/h and <10ml/h: KVO rate 1 ml/h
Flow rate <1ml/h: KVO rate = Flow rate
|
| Alarm |
Low battery, Battery exhausted, infusion near to end alarm,
Air in line, Occlusion, Door Open, Pause overtime,
VTBI completion, Malfunction A.C. and D.C. Off
|
| Occlusion Pressure |
Two levels: High, Low
H: 100 kpa ± 30 kpa; L: 50 kpa ± 20 kpa
|
| Power Adapter |
A.C. input power 100 V ~ 240 V 50/60 HZ; D.C. output power 15 V/2A |
| Lithium Battery |
Nominal Voltage: 10.8 V; Device can work over 6 hrs on battery |
| Infusion Pump Input Power |
D. C. 15 V |
| Power |
<55 VA |
| Classification |
Class II, Type CF, IPX2 |
| Weight |
1.5 kg |
| Dimension |
132 × 95 × 165 mm (W × D × H) |
